Wallenstein Tractor or Mini Skid Steer Backhoe Model GX620

Wallenstein Tractor or Mini Skid Steer Backhoe Model GX620

PRICE IS FOR BACKHOE ONLY! HOST MACHINE (TRACTOR / SKID STEER) NOT INCLUDED.

Check Wallenstein's Subframe List to see if your tractor is listed. Call us if you do not see your tractor listed 208-717-9671.

Break ground, not your back. When it comes to landscaping and excavating, start the job right with the Wallenstein Ranchho, the backhoe attachment that digs deeper and reaches further.

The Ranchho GX620 is designed for subcompact tractors. With a digging depth of 6'-4" and a 9-foot reach, the GX620 gets down and dirty, breaking the frostline and finishing the job quickly. The Ranchho gives you precision and power at your fingertips. The curved-boom backhoe is a versatile attachment that fits your tractor and your property. The Ranchho is a rugged backhoe that’s ready to sink its teeth into any task you give it, from landscaping to concrete footings.

The Ranchho is the perfect attachment for your tractor that gets the most out of your land. Landscaping, excavating and trenching soon become easy tasks with the digging power and reaching length of the Ranchho. Add a thumb to the Ranchho and start moving rocks into perfect position for your landscaping projects. For smaller tractors without hydraulics, the optional power pack gets you digging.

Features:
▪ Digging Depth: 6' 4" (193 cm)
▪ Engine HP Range (Tractor): 20 - 40
▪ Engine HP Range (Skidsteer): 20 - 50
▪ Required Hydraulic Flow: 4 - 12 gpm (15 - 45 lpm)
▪ Stabilizer Width (Spread) : 74" (188 cm)
▪ Main Boom Cylinder Diameter : 2.5" (64 mm)
▪ Dipper Cylinder Diameter : 2.25" (57 mm)
▪ Bucket Cylinder Diameter: 2.25" (57 mm)
▪ Number Of Swing Cylinders: 2
▪ Swing Cylinder Diameter: 2" (51 mm)
▪ Stabilizer Cylinder Diameter: 2" (51 mm)
▪ Reach From Swing Post : 100" (254 cm)
▪ Includes Flow Divider: No
▪ Bucket Rotation: 180°
▪ Swing Arc: 180°
▪ SAE* Dipper Boom Digging Force: 1250 lbs (567 kg)
▪ SAE* Bucket Digging Force: 2600 lbs (1179 kg)
▪ Boom Lift Capacity: 385 lbs (175 kg)
▪ Ground Clearance: 10.5" (27 cm)
▪ Loading Height: 62" (158 cm)
▪ Overall Operating Height (Fully Raised): 92" (234 cm)
▪ Total Weight: 575 lbs (261 kg)
▪ Transport Dimensions (LxWxH): 68" x 40" x 63" (173 cm x 102 cm x 160 cm)
▪ Operating Pressure: 1800 psi (12411 kPa)
▪ Mounting System: Subframe, Mini Skidsteer Universal Plate, PT302 (Cat I)
