100" Phoenix 3-Point Tractor Rotary Tiller Model T30-100GE
In Stock
SKU
UNI-PHO-T30-100GE
Compare at:
$16,894.00
Our Price:
$15,407.00
| Compare at | : | $16,894.00 | |
|---|---|---|---|
| Our Price | : | $15,407.00 | |
| Country Of Manufacture | : | United States | |
| SKU | : | UNI-PHO-T30-100GE | |
| Identifier | : | PHO-2952 | |
| Availability | : |
Ships in Approximately 3-5 Business Days. |
|
Questions? Call 208-717-9671
Images are representative but may vary from actual product and/or show optional features or colors.
In Stock
SAVE $1,487.00
T30 Series Gear Drive Rotary Tillers from Phoenix are extremely reliable and suited to even the most
demanding applications and soil conditions. The super strong frame, heavy duty steel plate box-type
bonnet, and four speed side drive in oil bath make these heavy duty machines dependable work
horses on any job. From the oversized rotor tube with optional double flange to the double extended
torque tubes, this machine is built to give you years of trouble free service.
Get the most out of your T30 Series Rotary Tiller with optional Roller Packer Kit, Hydraulic Roller Packer
Control Kit, and Double Flanged Rotor Tube.
Standard Features Include:
- Series 8 PTO Clutch With 4 Plate Slip Clutch by Eurocardan
- 6 Heavy Duty Tines Per Flange
- 2+2 Gearbox
- Gear Drive Transmission in Oil Bath
- Double Torque Tube
Available Options on Request:
- Double Flanges
- Roller Packer Kit
- Hydraulic Roller Packer Control Kit
- Spiked Roller Packer Kit
demanding applications and soil conditions. The super strong frame, heavy duty steel plate box-type
bonnet, and four speed side drive in oil bath make these heavy duty machines dependable work
horses on any job. From the oversized rotor tube with optional double flange to the double extended
torque tubes, this machine is built to give you years of trouble free service.
Get the most out of your T30 Series Rotary Tiller with optional Roller Packer Kit, Hydraulic Roller Packer
Control Kit, and Double Flanged Rotor Tube.
Standard Features Include:
- Series 8 PTO Clutch With 4 Plate Slip Clutch by Eurocardan
- 6 Heavy Duty Tines Per Flange
- 2+2 Gearbox
- Gear Drive Transmission in Oil Bath
- Double Torque Tube
Available Options on Request:
- Double Flanges
- Roller Packer Kit
- Hydraulic Roller Packer Control Kit
- Spiked Roller Packer Kit
| SKU | UNI-PHO-T30-100GE |
|---|---|
| Weight | 2725 lbs |
| Identifier | PHO-2952 |
| Model | T30-100GE |
| Horsepower Recommended | 90 - 160 HP (67.113 - 119.312 KW ) |
| Width - Overall | 100" (254 cm) |
| Width - Working | 100" (254 cm) |
| Tines / Rods | 60 Total - 6 Blades per Flange; 10 Flanges |
| Tilling Depth | Up to 8" (20 cm) |
| Unit Drive Type | 540 RPM Rear Tractor PTO |
| PTO Shaft | Included, Heavy Duty with Slip Clutch 1 3/8” ASAE Cat. 4 |
| Rotor Shaft Drive Type | Gear Driven |
| Skid Shoes | Adjustable and Replaceable, Included |
| Parking Stand | Included Standard |
| Color | Orange |
| Manufacturer | Phoenix |
