Managing the full potential of your forest is easy with the pulling strength of Wallenstein's FX-Series Bush Pilot Skidding Winches. You can now reach the trees you need to cut, even on steep hills or swampland without the need for large heavy equipment. The FX Skidding Winch is the ideal tractor attachment for gathering firewood, clearing dead trees and harvesting premium lumber all while preserving your woodlot.
Using a skidding winch is also easier on your tractor by transferring the pulling strain onto the ground with the large blade that anchors the winch. The Wallenstein FX Skidding Winch comes in three sizes to suit your tractor. Get more out of your woodlot with the Wallenstein FX Skidding Winch without the wear and tear on you, your woodlot or your tractor.
For larger tractors, the FX140 brings 14,000 lbs of pulling power to your woodlot. For furniture or firewood, if you have the logs the FX140 will bring them home. The 165’ cable length also provides plenty of distance so you can harvest trees that are well off the trail where your tractor won’t go.
Features:
• Pulling Capacity: 14000 lbs (6350 kg)
* Engine HP Range: 80 - 120
* Winch Type: Mechanical, Dry Disc Clutch
* Line Speed: 98 - 246 ft-min (30 - 75 m/min)
* Cable Type: Steel
* Cable Length: 165' (50 m)
* Cable Diameter: 1/2" (13 mm)
* Choker Chains: 2
* PTO Input Speed: 540 rpm
* PTO Height: 22" (56 cm)
* Total Weight: 898 lbs (407 kg)
* Dimensions (LxWxH): 28" x 59" x 80" (71 cm x 150 cm x 203 cm)
* Mounting System: Cat II
Options:
* Remote Control - For easy, efficient operation, all FX Skidding Winch models are available with a remote control option. Get full functionality from where ever you're standing.
* Choker Chains - Choker chains are ideal for winching multiple logs together, saving you time and energy. Each chained log is attached to a keyhole slider which gathers together as you begin to winch.
