72" Haugen Fork Mounted Carpet Pole Model MFCP 72-25

Made in USA.

72" Haugen Fork Mounted Carpet Pole

Features:
* Front mounted Fork Slot Carpet Poles
* Pole diameters available in 2.5", 2.75" and 3"
* Fork Pockets are 48" deep and will fit tines up to 2.5" thick x 6.5" wide
* Stress Proof or Fatigue Proof poles
* Available in 6', 9' and 10' lengths

Capacity, Pole Diameter: 2.50"
Model: MUCP 72-25
Capacity, Pole Tip: 1,500 lbs
Capacity, 1/2 Pole Length: 3,000 lbs
Capacity, Total (PLF): 500

Capacity, Pole Diameter: 2.75"
Model: MFCP 72-275
Capacity, Pole Tip: 2,000 lbs
Capacity, 1/2 Pole Length: 4,000 lbs
Capacity, Total (PLF): 660

Capacity, Pole Diameter: 3.00"
Model: MFCP 72-30
Capacity, Pole Tip: 2,600 lbs
Capacity, 1/2 Pole Length: 5,200 lbs
Capacity, Total (PLF): 860
