72" LS Tractor Rake Grapple Model MCG3172A
| Compare at | : | $3,695.00 | |
|---|---|---|---|
| Our Price | : | $3,510.00 | |
| SKU | : | LST-MCG3172A | |
| Identifier | : | LST-7094 | |
| Availability | : |
Back Ordered. Please contact us or call 208-717-9671 to confirm availability. |
|
Questions? Call 208-717-9671
Images are representative but may vary from actual product and/or show optional features.
72" LS Tractor Rake Grapple Model MCG3172A
Constructed of abrasion resistant AR400 steel. This grapple rake makes moving those large piles of unruly material a breeze. Have an acreage, farm or timber plot? This is the one attachment you quickly realize you can’t live without.
This grapple is equipped with large capacity, strong clamping power, 2 lever quick connect and heavy welded construction.
Features
â–ª Material: AR400
â–ª Weight (lb): 490
â–ª Overall width (in.); 76 3/4"
â–ª Rake width (in.): 75"
â–ª Closed height (in.): 31 1/2"
â–ª Jaw opening (in.): 41"
â–ª Side width (in.): 21 1/2"
â–ª Tooth thickness (in.): All outside teeth are 0.47" thick.
â–ª All teeth between outside teeth are 0.39" thick
â–ª Number of teeth: 12 Bottom & 11 Top
â–ª Hydraulic cylinder: 2" x 1-1/5" Rod (6" Stroke)
IMPORTANT: Requires 3rd Function Hydraulic Valve for operation.
Constructed of abrasion resistant AR400 steel. This grapple rake makes moving those large piles of unruly material a breeze. Have an acreage, farm or timber plot? This is the one attachment you quickly realize you can’t live without.
This grapple is equipped with large capacity, strong clamping power, 2 lever quick connect and heavy welded construction.
Features
â–ª Material: AR400
â–ª Weight (lb): 490
â–ª Overall width (in.); 76 3/4"
â–ª Rake width (in.): 75"
â–ª Closed height (in.): 31 1/2"
â–ª Jaw opening (in.): 41"
â–ª Side width (in.): 21 1/2"
â–ª Tooth thickness (in.): All outside teeth are 0.47" thick.
â–ª All teeth between outside teeth are 0.39" thick
â–ª Number of teeth: 12 Bottom & 11 Top
â–ª Hydraulic cylinder: 2" x 1-1/5" Rod (6" Stroke)
IMPORTANT: Requires 3rd Function Hydraulic Valve for operation.
| SKU | LST-MCG3172A |
|---|---|
| Weight | 490 lbs |
| Identifier | LST-7094 |
| Model | MCG3172A |
| Product Video | https://player.vimeo.com/video/528524868 |
| Horsepower Recommended | Up to 50 HP (37.3 KW) |
| Width - Overall | 76" (193 cm) |
| Maximum Opening | 41" (104 cm) |
| Tines / Rods | 7 Bottom Tines, 3/8" Width |
| Hydraulic Cylinder(s) | Two (2) Hydraulic Cylinders, Included |
| Hydraulic Hoses/Couplers | Hoses & Couplers Included |
| 3rd Function Hydraulic Valve | Required |
| Hitch Connection Type | Universal-Style Skid Steer Quick-Attach |
| Color | Gray |
| Manufacturer | LS Tractor |
