72" Rankin 3-Point Tractor Box Blade / Box Scraper Model BB20-72
| Compare at | : | $1,945.00 | |
|---|---|---|---|
| Our Price | : | $1,848.00 | |
| Country Of Manufacture | : | United States | |
| SKU | : | RAN-BB20-72 | |
| Identifier | : | RAN-1475 | |
| Availability | : |
Ships in Approximately 3-5 Business Days. |
|
Questions? Call 208-717-9671
Images are representative but may vary from actual product and/or show optional features or colors.
In Stock
SAVE $97.00
Made in USA.
Rankin BB20 Series 3-Point Tractor Box Scrapers are ideal for landscaping, grading, backfilling, scarifying, road maintenance and material moving applications.
The 20 Series Box Blades are available in 48", 54", 60", 66", 72" and 84" widths for tractors up to 40 HP. Equipped with manual adjustable heat-treated scarifier shanks with replaceable points and 1/2" x 6" reversible cutting edges.
Features:
▪ Cat. 1 quick hitch compatible
▪ 1/4" End Plates
▪ 1/2" x 6" reversible cutting edges
▪ Clevis style hitch
▪ Optional powder coat tractor matching colors
▪ Some assembly required.
Tractor-matching colors are available. Please call 208-717-9671 for availability.
* 1/4" End Plates
* 1/2" x 6" reversible cutting edges
* Clevis style hitch
* Optional powder coat tractor matching colors
* Some assembly required.
Tractor-matching colors are available. Please call 208-717-9671 for availability.
Rankin BB20 Series 3-Point Tractor Box Scrapers are ideal for landscaping, grading, backfilling, scarifying, road maintenance and material moving applications.
The 20 Series Box Blades are available in 48", 54", 60", 66", 72" and 84" widths for tractors up to 40 HP. Equipped with manual adjustable heat-treated scarifier shanks with replaceable points and 1/2" x 6" reversible cutting edges.
Features:
▪ Cat. 1 quick hitch compatible
▪ 1/4" End Plates
▪ 1/2" x 6" reversible cutting edges
▪ Clevis style hitch
▪ Optional powder coat tractor matching colors
▪ Some assembly required.
Tractor-matching colors are available. Please call 208-717-9671 for availability.
* 1/4" End Plates
* 1/2" x 6" reversible cutting edges
* Clevis style hitch
* Optional powder coat tractor matching colors
* Some assembly required.
Tractor-matching colors are available. Please call 208-717-9671 for availability.
| SKU | RAN-BB20-72 |
|---|---|
| Weight | 494 lbs |
| Identifier | RAN-1475 |
| Model | BB20-72 |
| Horsepower Recommended | 40 HP Maximum (29.8 kW) |
| Width - Overall | 72" (6 Feet; 183 cm) |
| Width - Working | 72" (6 Feet; 183 cm) |
| Moldboard | 16" Tall (41 cm) |
| End Plates | 1/4" Thick x 17" Tall x 24" Deep (.6 x 43 x 61 cm) |
| Shanks / Scarifiers | 6 - Manual Pinset Adjustment |
| Hydraulic Cylinder(s) | N/A |
| Hydraulic Hoses/Couplers | N/A |
| Cutting Edge | 1/2” x 6” Bolt-On / Reversible / Replaceable, Included |
| Hitch Connection Type | Category 1, 3-Point Hitch; Clevis Type; Quick-Hitch Compatible |
| Color | Gray (Other Colors Available/Optional) |
| Manufacturer | Rankin Equipment |
