78" Martatch Compact Tractor Snow Blade Model MSB78x20
| Compare at | : | $3,437.00 | |
|---|---|---|---|
| Our Price | : | $3,265.00 | |
| SKU | : | ELL-MAR-MSB78x20 | |
| Identifier | : | MAR-1410 | |
| Availability | : |
Back Ordered. Please contact us or call 208-717-9671 to confirm availability. |
|
Questions? Call 208-717-9671
Images are representative but may vary from actual product and/or show optional features.
78" Martatch Compact Tractor Snow Blade Model MSB78x20
THIS BLADE COMES STANDARD WITH A UNIVERSAL SKID STEER STYLE QUICK-ATTACH MOUNTING BRACKET. CAN BE BUILT TO MATCH ANY LOADER. PLEASE CALL 208-717-9671 WITH ANY QUESTIONS.
Martatch products are built to last a lifetime.
We have really been impressed with the Martatch snow blades, and Martatch equipment in general. These guys aren't messing around--they build good quality equipment the way it should be built. It starts with a good design and continues through the build process with care and attention to detail. You get what you pay for with Martatch Attachments.
Features:
* 20" high moldboard
* 78" working width
* For up to 50 HP
* Available with undercarriage mount
* Spring trip moldboard
* Lateral float
* Manual or hydraulic angle 30 degrees both ways
* Optional hydraulic angle complete with cross-over relief valve protection
* Adjustable skid shoes
* Reversible cutting edge for longer wear life
* Skid steer style quick-attach standard, but can be made to fit any loader.
IMPORTANT: If equipped with Hydraulic Angle a
3rd Function Hydraulic Valve is Required for operation.
Call 208-717-9671 for more information.
THIS BLADE COMES STANDARD WITH A UNIVERSAL SKID STEER STYLE QUICK-ATTACH MOUNTING BRACKET. CAN BE BUILT TO MATCH ANY LOADER. PLEASE CALL 208-717-9671 WITH ANY QUESTIONS.
Martatch products are built to last a lifetime.
We have really been impressed with the Martatch snow blades, and Martatch equipment in general. These guys aren't messing around--they build good quality equipment the way it should be built. It starts with a good design and continues through the build process with care and attention to detail. You get what you pay for with Martatch Attachments.
Features:
* 20" high moldboard
* 78" working width
* For up to 50 HP
* Available with undercarriage mount
* Spring trip moldboard
* Lateral float
* Manual or hydraulic angle 30 degrees both ways
* Optional hydraulic angle complete with cross-over relief valve protection
* Adjustable skid shoes
* Reversible cutting edge for longer wear life
* Skid steer style quick-attach standard, but can be made to fit any loader.
IMPORTANT: If equipped with Hydraulic Angle a
3rd Function Hydraulic Valve is Required for operation.
Call 208-717-9671 for more information.
| SKU | ELL-MAR-MSB78x20 |
|---|---|
| Weight | 490 lbs |
| Identifier | MAR-1410 |
| Model | MSB78x20 |
| Horsepower Recommended | 20 - 35 HP (14.9 - 26.1 KW) |
| Width - Overall | 78" (6-1/2 Feet; 198 cm) |
| Width - Working | 78" (6-1/2 Feet; 198 cm) |
| Width - Fully Angled | 68" (173 cm) |
| Moldboard | 20" Tall (51 cm) x 3/16" (.5 cm) Thick |
| Spring Trip | Spring Trip Moldboard (Full Blade) |
| Angle | 30 Degree Hydraulic Angle Left and Right Standard (includes hoses; couplers optional) |
| Tilt | Lateral Float Follows Ground Contours |
| Blade End Guide Markers | Optional |
| Hydraulic Cylinder(s) | Single Hydraulic Cylinder, Included |
| 3rd Function Hydraulic Valve | Required for Hydraulic Angle |
| Skid Shoes | AR400 Steel Adjustable and Replaceable, Included |
| Cutting Edge | 3/8" x 6" Bolt-On / Reversible / Replaceable, Included |
| Hitch Connection Type | Universal-Style Skid Steer Quick-Attach (Others Optional) |
| Color | Yellow |
| Manufacturer | Martatch |
