Erskine Tree Spade 4S Model 901166
| Compare at | : | $17,435.00 | |
|---|---|---|---|
| Our Price | : | $14,471.00 | |
| Country Of Manufacture | : | United States | |
| SKU | : | ERS-901166 | |
| Identifier | : | ERS-4721 | |
| Availability | : |
Ships in Approximately 7-10 Business Days. |
|
| Best Price Promise | : | Found a lower TOTAL DELIVERED PRICE elsewhere? Let us know and we will do our best to beat it! | |
Questions? Call 208-717-9671
Images are representative but may vary from actual product and/or show optional features or colors.
Made in USA.
Turn your skid loader into a high-speed, labor-saving transplanting unit. A tree can be dug or transplanted without the operator having to leave the loader. Spade is designed with a very short frame reducing the need for stabilizers and counterweights. The blades of the tree spade overlap to ensure clean root cutting and support of the root ball.
Features
* Tree Spade comes complete and ready to use, including all-hydraulic hoses, couplers, and controls
* Good for transplanting hardwood trees to 2 1/2” diameter and evergreens to 3”
* Three steel cutting blades are 3/8” thick
* Adjustable control valve stand
* All joints outfitted with grease fittings
* Removable blades for easy sharpening
* Short frame design for increased down-pressure reducing the need for rear stabilizers
Turn your skid loader into a high-speed, labor-saving transplanting unit. A tree can be dug or transplanted without the operator having to leave the loader. Spade is designed with a very short frame reducing the need for stabilizers and counterweights. The blades of the tree spade overlap to ensure clean root cutting and support of the root ball.
Features
* Tree Spade comes complete and ready to use, including all-hydraulic hoses, couplers, and controls
* Good for transplanting hardwood trees to 2 1/2” diameter and evergreens to 3”
* Three steel cutting blades are 3/8” thick
* Adjustable control valve stand
* All joints outfitted with grease fittings
* Removable blades for easy sharpening
* Short frame design for increased down-pressure reducing the need for rear stabilizers
| SKU | ERS-901166 |
|---|---|
| Weight | 1935 lbs |
| Identifier | ERS-4721 |
| Model | 901166 |
| Horsepower Recommended | N/A |
| Tree Size (Evergreen) | 4" (10 cm) |
| Tree Size (Hardwood) | 3" (8 cm) |
| Root Ball Diameter | 40" (102 cm) |
| Root Ball Depth | 30" (76 cm) |
| Blade(s) / Teeth | 1/4" High Alloy |
| Blade Truncation | Full |
| Slides | Steel |
| Outside Towers Swing Open (Swing Hinge Frame) | Yes |
| Function Controls | Hydraulic Standard; Electric Optional |
| Required Hydraulic Flow | 5 - 25 gpm (18.9 - 94.6 lpm) |
| Required Hydraulic Remote(s) | 1 Set |
| Hydraulic Hoses/Couplers | Hydraulic Hoses & Couplers Included |
| Hitch Connection Type | Skid Steer Quick-Attach Standard (Mini Skid Steer Optional) |
| Color | Black |
| Manufacturer | Erskine Attachments |
