Wallenstein 5" Tractor Wood Chipper Model BXTR5224

Heavy Duty Chipping Power. At the heart of the Wallenstein BXTR Chipper is an oversize heavy duty rotor and reversible chipping blades. The large diameter rotor has a faster tip speed for improved chipping action. The heavy gauge steel keeps your momentum to power through tree trunks. The reversible blades are precision cut tool steel, hardened for long lasting sharpness.

Turn branches and leaves into a valuable resource that's perfect for pathways and flowerbeds with a Wallenstein Chipper. Chipping is your best method of reducing large, awkward branches to a fraction of their size, making handling easy and creating a useful ground cover that helps control weeds and retain moisture in hot weather.

There are no belts or pulleys to worry about when you’re in the woods. Directly connected to your tractor's PTO, power is transferred straight into chipping action. 5" diameter logs are quickly mulched with the BXTR5224.

With a PTO powered rotor and hydraulic feed hopper, branches, limbs and brush are control fed for continuous chipping at maximum capacity.

* Chipping Capacity: 5" (13 cm)
* Chipper Type: Disc
* Feed System: Hydraulic Roller Feed with Intellifeed II Technology
* Max. Feed Rate: 85 fpm (26 mpm)
* Engine: 688 CC Honda GX690
* Chipper Hopper Opening: 24" x 35" (61 cm x 89 cm)
* Chipper Housing Opening: 5.25" x 9" (13 cm x 23 cm)
* Number Of Chipper Knives: 2
* Rotor Diameter: 25" (64 cm)
* Rotor Weight : 117 lbs (53 kg)
* Discharge Chute Height: 80" (203 cm)
* Discharge Chute Rotation: 360°
* Drive System: Centrifugal Clutch, Belt Drive
* Engine RPM: 3600
* Rotor RPM: 1340
* Tires: 5.30-12
* Hitch: 2" Ball
* Electric Brakes: No
* Total Weight: 1425 lbs (646 kg)
* Dimensions Open (LxWxH): 126" x 54" x 80" (320 cm x 137 cm x 203 cm)
* Dimensions Folded (LxWxH): 107" x 54" x 80" (320 cm x 137 cm x 203 cm)
* Hydraulic Capacity: 5 US gal (19 l)
* Fuel Tank Capacity: 6.5 US gal (25 l)

Rotor - At the heart of the Wallenstein BX Chipper is an oversize heavy duty rotor and reversible chipping blades. The large diameter rotor has a faster tip speed for improved chipping action and the heavy gauge steel keeps your momentum to power through 5” diameter tree trunks.

Blades - The reversible blades are precision cut tool steel and hardened, keeping a sharp cutting edge and maximizing the performance of the chipper.

Air Vents - Blowing force is maximized with air intake vents on the side of the chipper. Air enters through the vents and powers the chips out the chute up to 20 feet.

Twig Breaker Blower Paddles - Behind the blades are blower paddles with integrated twig breakers designed for greater output force and smaller chips exiting the machine. This provides more consistent chip size and allows you to propel the chips further.

Adjustable Chute - Easily control where you want the chips with the double adjustable Exit Chute. The chute swivels 360 degrees and the top deflector adjusts the distance.

Mounting Configurations - There are three different mounting configurations available for the BX Wood Chipper; A three point hitch, skidsteer mount and trailer.

Hydraulic Feed Hopper - Maximize your chipping with the aggressive hydraulic feed hopper. Chipping becomes effortless when you let the rotating teeth do all the work. As the brush is fed into the chipper, you can be ready with the next piece.

Match Your Style - This unit is available in tractor-matching colors: Red, Orange, Green, Blue, Yellow. We typically stock red and/or orange. Please call 208-717-9671 for color availability.
