Wallenstein 7" 3-Point Tractor PTO Wood Chipper with Hydraulic Feed Model BX72R

In Stock
SKU
ELL-WAL-BX72R
Compare at: $13,120.00 Our Price: $12,464.00
Our Price : $13,120.00

Add to Cart for our Best Price

SKU : ELL-WAL-BX72R
Identifier : WAL-3273
Availability :

Back Ordered. Please contact us or call 208-717-9671 to confirm availability.

Wallenstein 7" 3-Point Tractor PTO Wood Chipper with Hydraulic Feed Model BX72R
Wallenstein 7" 3-Point Tractor PTO Wood Chipper with Hydraulic Feed Model BX72R Wallenstein 7" 3-Point Tractor PTO Wood Chipper with Hydraulic Feed Model BX72R Wallenstein 7" 3-Point Tractor PTO Wood Chipper with Hydraulic Feed Model BX72R Wallenstein 7" 3-Point Tractor PTO Wood Chipper with Hydraulic Feed Model BX72R

Images are representative but may vary from actual product and/or show optional features.

SAVE $656.00
Heavy Duty Chipping Power. At the heart of the Wallenstein BX Chipper is an oversize heavy duty rotor and reversible chipping blades. The large diameter rotor has a faster tip speed for improved chipping action. The heavy gauge steel keeps your momentum to power through tree trunks. The reversible blades are precision cut tool steel, hardened for long lasting sharpness.

Turn branches and leaves into a valuable resource that's perfect for pathways and flowerbeds with a Wallenstein Chipper. Chipping is your best method of reducing large, awkward branches to a fraction of their size, making handling easy and creating a useful ground cover that helps control weeds and retain moisture in hot weather.

There are no belts or pulleys to worry about when you’re in the woods. Directly connected to your tractor's PTO, power is transferred straight into chipping action. 7" diameter logs are quickly mulched with the BX72R.

With a PTO powered rotor and hydraulic feed hopper, branches, limbs and brush are control fed for continuous chipping at maximum capacity.

* Chipping Capacity: 7" (18 cm)
* Chipper Type: Disc
* Feed System: Dual Hydraulic Roller Feed
* Engine HP Range: 50 - 85
* Required Hydraulic Flow: 3 - 6 gpm (12 - 23 lpm)
* Chipper Hopper Opening: 26” x 35” (66 cm x 89 cm)
* Chipper Housing Opening: 7" x 12" (18 cm x 31 cm)
* Number Of Chipper Knives: 4
* Rotor Diameter: 28” (71 cm)
* Rotor Weight : 185 lbs (84 kg)
* Discharge Chute Height: 90” (228 cm)
* Discharge Chute Rotation: 360°
* Drive System: PTO Direct Drive
* Rated RPM: 540 - 1000
* Total Weight: 1300 lbs (590 kg)
* Dimensions Open (LxWxH): 108" x 64" x 90" (275 cm x 163 cm x 229 cm)
* Dimensions Folded (LxWxH): 83" x 56" x 90" (211 cm x 143 cm x 229 cm)
* Mounting System: Cat I, iMatch™ & Quick Hitch Compatible

Rotor - At the heart of the Wallenstein BX Chipper is an oversize heavy duty rotor and reversible chipping blades. The large diameter rotor has a faster tip speed for improved chipping action and the heavy gauge steel keeps your momentum to power through 6” diameter tree trunks.

Blades - The reversible blades are precision cut tool steel and hardened, keeping a sharp cutting edge and maximizing the performance of the chipper.

Air Vents - Blowing force is maximized with air intake vents on the side of the chipper. Air enters through the vents and powers the chips out the chute up to 20 feet.

Twig Breaker Blower Paddles - Behind the blades are blower paddles with integrated twig breakers designed for greater output force and smaller chips exiting the machine. This provides more consistent chip size and allows you to propel the chips further.

Adjustable Chute - Easily control where you want the chips with the double adjustable Exit Chute. The chute swivels 360 degrees and the top deflector adjusts the distance.

Mounting Configurations - There are three different mounting configurations available for the BX Wood Chipper; A three point hitch, skidsteer mount and trailer.

Hydraulic Feed Hopper - Maximize your chipping with the aggressive hydraulic feed hopper. Chipping becomes effortless when you let the rotating teeth do all the work. As the brush is fed into the chipper, you can be ready with the next piece.

Match Your Style - This unit is available in tractor-matching colors: Red, Orange, Green, Blue, Yellow. We typically stock red and/or orange. Please call 208-717-9671 for color availability.
More Information
SKU ELL-WAL-BX72R
Weight 1300 lbs
Identifier WAL-3273
Model BX72R
Product Video https://www.youtube.com/watch?v=YpFj2hZu9Pw
Required Hydraulic Flow 3 - 6 gpm (12 - 23 lpm)
Capacity 7" (18 cm) Diameter
Rotor Diameter: 28" (71 cm); Weight: 185 lbs. (84 kg)
Knives / Teeth 4 Hardened Tool Steel Rotor Knives
Feed System Hydraulic
Unit Drive Type 540 or 1,000 RPM Rear Tractor PTO
PTO Speed 540 RPM or 1,000 RPM
PTO Shaft Included, with Shear-Bolt Protection
Hitch Connection Type Category 1/2, 3-Point Hitch, Quick-Hitch Compatible
Color Yellow (Other Colors Available/Optional)
Manufacturer Wallenstein
